Postgres Language Server: implementing the Parser

2023-12-08

26 minute read

During our previous Launch Week we announced the development of a Postgres Language Server. The response was more enthusiastic than we imagined and we received some excellent ideas.

This is an update on the Parser, which is the fundamental primitive of a Language Server. We’ve been through several iterations of the parser and we want to detail our explorations.

Want to learn some more acronyms?

There will be a few acronyms in this post. We don’t want this post to be “inside baseball” so here are a few concepts that you need to know:

  • LSP / Language Server Protocol: Something that helps code editors understand code better. It provides functionality like linting and error detection.
  • Postgres Language Server: a server that will help with Postgres programming - writing SQL, type inference, etc.
  • Parser: A parser converts written code into a form that tools can work with. For example, it identifies variables in code. and then the tools can easily access those variables. We’ll describe this more below.

Background: Why build a Language Server?

Postgres is gaining popularity, and yet the tooling around it still needs a lot of work. Writing SQL in editors like VSCode is a pain. One of the unique features of Supabase is the ability to access your Postgres database from a browser or mobile app through our Data APIs. This means that developers are writing more PL/pgSQL.

While code editors have great support for most programming languages, SQL support is underwhelming. We want to make Postgres as simple as Python.

Language Server's Core: The Role of the Parser

On the highest level, a language server is a thing which

  1. accepts input source code from the client
  2. turns it into a semantic model of the code
  3. and provides language-specific smarts back to the client.

The parser is the core of every language server. It takes the raw string, turns it into a stream of tokens, and builds a syntax tree. This syntax tree can then be used to extract structural information.

Usually, the parser builds a concrete syntax tree (CST) before turning it into an abstract syntax tree (AST). A CST preserves all syntax elements present in the source code with the goal of being able to re-create the exact original source, while an AST contains only the meaning of the source. For example, take a simple expression 2 * (7 + 3):


_15
CST AST
_15
----- -----
_15
expr *
_15
/ | \ / \
_15
term * term 2 +
_15
| | / \
_15
factor factor 7 3
_15
| / | \
_15
2 ( expr )
_15
/ | \
_15
term + term
_15
| |
_15
factor factor
_15
| |
_15
7 3

Implementing a Parser for Postgres

Implementing a parser for Postgres is challenging because of the ever-evolving and complex syntax of Postgres. Even select statements are very complex to parse. Then there are common table expressions, sub-queries and the like. This is one of the reasons why existing Postgres tooling is scarce, badly maintained, and often does not work well.

We decided to not create a custom parser. Instead, we leverage libpg_query to parse SQL code reliably. The pganalyze team has a published a great blog post on why this approach is preferable.

However, libpgquery is designed to parse _executable SQL — not to provide language intelligence. Using it for a language server means adapting it to our specific use case. Let’s explore how we adapted it:

Tokenization

Before any syntax tree can be built, the input string needs to be converted into a stream of tokens. libpg_query exposes a scan API that returns all non-whitespace tokens of the source, even for invalid SQL. For example, a simple statement select '1'; returns


_18
ScanToken {
_18
start: 0,
_18
end: 6,
_18
token: Select,
_18
keyword_kind: ReservedKeyword,
_18
},
_18
ScanToken {
_18
start: 7,
_18
end: 10,
_18
token: Sconst,
_18
keyword_kind: NoKeyword,
_18
},
_18
ScanToken {
_18
start: 10,
_18
end: 11,
_18
token: Ascii59,
_18
keyword_kind: NoKeyword,
_18
}

Every ScanToken token contains its variant, a range, and a keyword kind. To simplify the implementation of the parser, we extract the text for each token using the range for now. We arrive at the following Token struct.


_10
pub struct Token {
_10
/// The kind of the token
_10
pub kind: SyntaxKind,
_10
/// Text from the input
_10
pub text: String,
_10
/// Range within the input
_10
pub span: TextRange,
_10
/// Variants from `ScanToken.keyword_kind` + `Whitespace`
_10
pub token_type: TokenType,
_10
}

To have a complete token stream, we merge the results of scan with a list of all whitespace tokens in the source, where the latter are extracted by a simple regular expression. For a simple statement select '1';, the following tokens are returned by the lexer.


_26
[
_26
Token {
_26
kind: Select,
_26
text: "select",
_26
span: 0..6,
_26
token_type: ReservedKeyword,
_26
},
_26
Token {
_26
kind: Whitespace,
_26
text: " ",
_26
span: 6..7,
_26
token_type: Whitespace,
_26
},
_26
Token {
_26
kind: Sconst,
_26
text: "'1'",
_26
span: 7..10,
_26
token_type: NoKeyword,
_26
},
_26
Token {
_26
kind: Ascii59,
_26
text: ";",
_26
span: 10..11,
_26
token_type: NoKeyword,
_26
},
_26
]

Conversion to a Syntax Tree

To transform the stream of tokens into a syntax tree, we face the first challenges with libpg_query. In a language server, it's important to handle incomplete or improperly formatted input gracefully. When an error occurs you don’t want the parser to “stop”. You want it to check for all errors in your code:


_10
create table posts (
_10
id serial primary key # <- ERR: missing comma, Parser should continue
_10
content text
_10
);
_10
_10
create table comments (
_10
id serial primary key,
_10
post_id int references posts # <- ERR: missing comma, second error returned
_10
comment text
_10
);

Unfortunately, the parse api from libpg_query only parses the entire input — if any SQL statement contains a syntax error, an error is returned for the entire input.

To overcome this, we implemented a resilient source parser. This parser breaks the input into individual SQL statements and parses them one by one, allowing us to handle syntax errors within each statement independently. It is implemented as a top-down LL parser. Specifically, the parser iterates the token stream left-to-right, and checks if the cursor currently is at the start of a new statement. Once a statement is entered, it walks the tokens until ; or another statement start is encountered while skipping sub-statements.

Luckily, Postgres statements always start with distinct keywords. An update statement is identifiable with update, a delete statement with delete from. There are a few statements that need more than the first few tokens to be distinguishable, but we only care about whether there is a statement, and not what statement there is exactly, so ambiguity is very much acceptable.

For the implementation, we only need to provide the distinct keywords each statement starts with and compare it to the current tokens using a lookahead mechanism.

Reverse-Engineering the CST

The second limitation we encountered: libpg_query only exposes an API for the AST, not for the CST. To provide language intelligence on the source code, both are required. Since we do not want to implement our own parser, we need to work with what we have to build the CST: the AST and a stream of tokens. The goal is to reverse-engineer the AST into the CST. This involves re-using the AST nodes as CST nodes, and figuring out what token belongs beneath what node. The exemplary statement select '1'; should be be parsed into


_10
SelectStmt@0..11
_10
Select@0..6 "select"
_10
Whitespace@6..7 " "
_10
ResTarget@7..10
_10
AConst@7..10
_10
Sconst@7..10 "'1'"
_10
Ascii59@10..11 ";"

To do that, we need to know the range of every node that is within the AST.

We made numerous iterations over the past few months to figure out how to accomplish this with minimal manual implementations. Before diving into details, lets take a closer look at the parse API of libpg_query. For the exemplary statement above, it returns (simplified for readability):


_23
SelectStmt {
_23
target_list: [
_23
ResTarget {
_23
val: Some(
_23
Node {
_23
node: Some(
_23
AConst {
_23
location: 7,
_23
val: Some(
_23
Sval(
_23
String {
_23
sval: "1",
_23
},
_23
),
_23
),
_23
},
_23
),
_23
},
_23
),
_23
location: 7,
_23
},
_23
],
_23
}

There are a few limitations:

  1. Some nodes do have a location property that indicates where the node starts in the source, but not all.
  2. There is no information on the range of a node within the source.
  3. Some locations are not what you would expect. For example the location of the expression node is the location of the operator, not the start of the left expression.

To summarise: we need a range for each node, and we only have a start position, but not always, and sometimes it is wrong.

Our first very iterations were naive. We explored what information we could extract from scan and parse, and if anything can help in reverse-engineering the CST.

It turns out, the most reliable way of determining the range of a node is by knowing all properties of that node, and its position in the tree.

A property is any text for which a Token can potentially be found in the source code. For example, a SelectStmt node has the select keyword as a property, and if there is a from_clause, a from keyword. For the exemplary statement above, the properties are


_10
SelectStmt: [Select],
_10
RangeVar: [],
_10
AConst: ['1']

Note that we do not have an extra String node, and instead add its properties to the parent AConst node. This reason is that a String node does not bring any value to the CST, since we already know that ‘1' is a string from the kind of the respective Token. The same is true for all nodes that just contain type information such as Integer, Boolean and Float.

The position of any node is the same in AST and CST, and thereby can be reflected from it.

Implementation

Before the actual parsing begins, the AST returned by parse is converted into an uniform tree structure where each node holds the kind of the node, a list of properties, the depth and, if available, the location.

For example, for select '1';:


_39
edges: (0, 1), (1, 2),
_39
nodes: {
_39
0: Node {
_39
kind: SelectStmt,
_39
depth: 1,
_39
properties: [
_39
TokenProperty {
_39
value: None,
_39
kind: Some(
_39
Select,
_39
),
_39
},
_39
],
_39
location: None,
_39
},
_39
1: Node {
_39
kind: ResTarget,
_39
depth: 2,
_39
properties: [],
_39
location: Some(
_39
7,
_39
),
_39
},
_39
2: Node {
_39
kind: AConst,
_39
depth: 3,
_39
properties: [
_39
TokenProperty {
_39
value: Some(
_39
"1",
_39
),
_39
kind: None,
_39
},
_39
],
_39
location: Some(
_39
7,
_39
),
_39
},
_39
},

To implement such a conversion we need a way to

  • get an Option<usize> with the location for every node type, if any
  • compile a list of all properties that a node contains
  • walk down the AST until the leaves are reached

Due to the strict type system of Rust, a manual implementation would be a significant and repetitive effort. With languages such as JavaScript, getting the location of a node would be as simple as node?.location. In Rust, a large match statement covering all possible nodes is required to do the same. Luckily, libpg_query exports a protobuf definition containing all AST nodes and their fields. For example, an AExpr node is defined as


_10
message A_Expr
_10
{
_10
A_Expr_Kind kind = 1 [json_name="kind"];
_10
repeated Node name = 2 [json_name="name"];
_10
Node lexpr = 3 [json_name="lexpr"];
_10
Node rexpr = 4 [json_name="rexpr"];
_10
int32 location = 5 [json_name="location"];
_10
}

We introspect that definition to generate code at build time using procedural macros.

Leveraging the powerful repetition feature of the [quote](https://github.com/dtolnay/quote) crate, the match statement of a get_location function can be implemented with just a few lines of code.


_20
pub fn get_location_mod(_item: proc_macro2::TokenStream) -> proc_macro2::TokenStream {
_20
// Parse the proto file using a custom parser
_20
let parser = ProtoParser::new("libpg_query/protobuf/pg_query.proto");
_20
let proto_file = parser.parse();
_20
_20
// get all node identifiers for the left side of the match arm
_20
let node_identifiers = node_identifiers(&proto_file.nodes);
_20
// get a TokenStream for each node that returns the location
_20
// if it is part of the node properties
_20
let location_idents = location_idents(&proto_file.nodes);
_20
_20
quote! {
_20
/// Returns the location of a node
_20
pub fn get_location(node: &NodeEnum) -> Option<usize> {
_20
match node {
_20
#(NodeEnum::#node_identifiers(n) => #location_idents),*
_20
}
_20
}
_20
}
_20
}

The location_idents function iterates all nodes, searches for a location property in the protobuf definition for each node, and returns a TokenStream with either Some(n.location) or None for each.


_18
fn location_idents(nodes: &[Node]) -> Vec<TokenStream> {
_18
nodes
_18
.iter()
_18
.map(|node| {
_18
if node
_18
.fields
_18
.iter()
_18
// has location property?
_18
.find(|n| n.name == "location" && n.field_type == FieldType::Int32)
_18
.is_some()
_18
{
_18
quote! { Some(n.location) }
_18
} else {
_18
quote! { None }
_18
}
_18
})
_18
.collect()
_18
}

Similarly, we can generate code to recursively walk down the FieldType == Node and FieldType == Vec<Node> properties of the AST nodes. No manual work required.

Even the function that returns all properties for a node can be generated, at least partly. All AST fields of FieldType == String can always be added to the list of properties. In the example above, the sval: “1” of the String node makes up the properties of its parent, the AConst node. What is remaining are mostly just the keywords that need to be defined for every node. A SelectStmt node has the select keyword as a property, and if there is a from_clause, a from keyword.


_11
fn custom_handlers(node: &Node) -> TokenStream {
_11
match node.name.as_str() {
_11
"SelectStmt" => quote! {
_11
tokens.push(TokenProperty::from(Token::Select));
_11
if n.from_clause.len() > 0 {
_11
tokens.push(TokenProperty::from(Token::From));
_11
}
_11
...
_11
},
_11
...
_11
}

Parsing a Statement

After the tree has been generated, the parser goes through the tokens and finds the node in whose properties the current token can be found. But not every node is a possible successor. Lets look how the parser builds the CST for the statement select '1' from contact at a high level.

We start with the full tree, and all tokens:


_10
Remaining Tokens: ["select", "'1'", "from", "contact"]
_10
_10
Parse Tree:
_10
_10
SelectStmt (0, [Select, From])
_10
/ \
_10
1 (ResTarget, []) 2 (RangeVar, ['contact'])
_10
|
_10
3 (AConst, ['1'])

Starting with the root node, the parser first searches the current node for the token. In this case, with success. Select is removed from SelectStmt .

In the next iteration, we search for '1'. Since its not in the current node, a breadth-first search is used to find the property within children nodes. We arrive at AConst , open all nodes we encountered along the way, and advance.


_17
Remaining Tokens: ["from", "contact"]
_17
_17
Parse Tree:
_17
_17
SelectStmt (0, [From])
_17
/ \
_17
1 (ResTarget, []) 2 (RangeVar, ['contact'])
_17
|
_17
3 (AConst, [])
_17
_17
CST:
_17
SelectStmt
_17
Select@0..6 "select"
_17
Whitespace@6..7 " "
_17
ResTarget@7..10
_17
AConst@7..10
_17
Sconst@7..10 "'1'"

Since we arrived at a leaf node with no properties left, the next token can not be part of this node or any child. It can be closed immediately after advancing the token. We remove it from the tree and set the current node to its parent. The same now applies to ResTarget, so we arrive back at SelectStmt:


_15
Remaining Tokens: ["from", "contact"]
_15
_15
Parse Tree:
_15
_15
SelectStmt (0, [From])
_15
\
_15
2 (RangeVar, ['contact'])
_15
_15
CST:
_15
SelectStmt
_15
Select@0..6 "select"
_15
Whitespace@6..7 " "
_15
ResTarget@7..10
_15
AConst@7..10
_15
Sconst@7..10 "'1'"

The from token can once again be found within the current node and we just advance the parser. Since SelectStmt is not a leaf node, we stay where we are.


_17
Remaining Tokens: ["contact"]
_17
_17
Parse Tree:
_17
_17
SelectStmt (0, [])
_17
\
_17
2 (RangeVar, ['contact'])
_17
_17
CST:
_17
SelectStmt
_17
Select@0..6 "select"
_17
Whitespace@6..7 " "
_17
ResTarget@7..10
_17
AConst@7..10
_17
Sconst@7..10 "'1'"
_17
Whitespace@10..11 " "
_17
From@11..15 "from"

From here, it repeats itself: contact is found within RangeVar using a breadth-first search. It becomes a leaf node that is closed after applying the token. Since no tokens are left, we finish parsing by closing SelectStmt, resulting in:


_11
SelectStmt@0..23
_11
Select@0..6 "select"
_11
Whitespace@6..7 " "
_11
ResTarget@7..10
_11
AConst@7..10
_11
Sconst@7..10 "'1'"
_11
Whitespace@10..11 " "
_11
From@11..15 "from"
_11
Whitespace@15..16 " "
_11
RangeVar@16..23
_11
Ident@16..23 "contact"

Keep in mind, this illustration shows you only an overview of the process.If you are interested in the details, take a look at the source code here.

You may have noticed that neither location nor depth were mentioned. Both are only used to improve performance and safeguard. Among other things, branches with nodes behind the current position of the parser are skipped. Further, the parser panics when a node is opened and either its position or its depth does not match the current state of the parser. This means that the returned CST is guaranteed to be correct.

Limitations

If the SQL is invalid and parse returns an error, the returned CST is just a flat list of tokens. Consequently, the statement parser is not resilient. This is not great, but we have intentionally implemented it so that custom and resilient implementations can be added statement by statement later.

Ultimately, we want the libpg_query-based parser to just serve as a fallback. For now however, our goal is to provide a usable language server as fast as possible. And even if some intelligence features will only work on valid statements, we believe it is still better than what we have today: no intelligence at all.

Next Steps

There are some minor improvements remaining for the parser. But the largest part are the manual implementations missing in get_node_properties . Its a time-consuming effort, and we would love to get help from the community here. Check out this issue if you like to support.

After that, we will move on to the semantic data model and the language server itself. Other parser features such as support for PL/pgSQL function body parsing will be added later. We want to get this project into a usable state as fast as possible.

Share this article

Build in a weekend, scale to millions
